Description
One system, many possible combinations. Choose the right lithotripsy basket for every situation and simply combine it with the ENDO-FLEX metal spiral and the lithotriptor handle.
- 4 wire baskets, lozenged and twisted
- 6-wire basket lozenged and twisted
- guide wire-compatible basket variants
- stainless steel spirals for standard and emergency lithotripsy
- pre-assembled set configurations
Customer Service
More Information
Lithotripsy Basket – 4 Braided Wire
Suitable for lithotripsy handle type I (no more available) & type III; tube length: 195 cm; total system length: 400 cm
| Catalogue No. | Description | Sheath Outer Diameter (mm) | Suitable for Lithotripsy Spiral Ø (mm) | Basket Width in Opened Condition (mm) | Basket Length in Stretched Condition (mm) |
|---|---|---|---|---|---|
| E122264N | 4-Wire Basket Type | 2.6 | 2.6 | ~20 | 40 |
| E122265N | 4-Wire Basket Type | 2.6 | 2.6 | ~25 | 50 |
| E122266N | 4-Wire Basket Type | 2.6 | 2.6 | ~30 | 70 |
| E122267N | 4-Wire Basket Type | 2.6 | 2.6 | ~35 | 70 |
| E122336N | 4-Wire Basket Type | 2.9 | 3.3 | ~30 | 60 |
Lithotripsy Basket – 6 Braided Wire
Suitable for lithotripsy handle type I (no more available) & type III; tube length: 195 cm; total system length: 400 cm
| Catalogue No. | Description | Sheath Outer Diameter (mm) | Suitable for Lithotripsy Spiral Ø (mm) | Basket Width in Opened Condition (mm) | Basket Length in Stretched Condition (mm) |
|---|---|---|---|---|---|
| E124263N | 6-Wire Dormia Type | 2.6 | 2.6 | ~12 | 30 |
| E124264N | 6-Wire Dormia Type | 2.6 | 2.6 | ~18 | 40 |
| E124265N | 6-Wire Dormia Type | 2.6 | 2.6 | ~25 | 50 |
| E124266N | 6-Wire Dormia Type | 2.6 | 2.6 | ~30 | 60 |
| E124267N | 6-Wire Dormia Type | 2.6 | 2.6 | ~35 | 70 |
| E124335N | 6-Wire Dormia Type | 2.9 | 3.3 | ~25 | 50 |
| E124337N | 6-Wire Dormia Type | 2.9 | 3.3 | ~35 | 70 |
| E128336N | 6-Wire Dormia Type | 2.9 | 3.3 | ~30 | 60 |
Fitting Lithotripsy Handles – Mechanical Lithotripsy
| Catalogue No. | Description |
|---|---|
| 120600 | Lithotripsy Handle Type III Reusable, user-friendly twist & pull technology, 1-push safety system suitable for planned and emergency Lithotripsy |
Lithotripsy Spiral
Made of stainless steel
| Catalogue No. | Suitable for Lithotripsy Handle | Outer Diameter (mm) | Total Length (cm) |
|---|---|---|---|
| E120261 | Type I (no more available) | 2.6 | 195 |
| E120602 | Type III | 2.6 | 195 |
Emergency Lithotripsy Spiral
Made of stainless steel
| Catalogue No. | Suitable for Lithotripsy Handle | Outer Diameter (mm) | Total Length (cm) |
|---|---|---|---|
| E120604 | Type III | 4.0 | 100 |
Lithotripsy Set Type III
Consists of storage case, handle, spirals and baskets
| Catalogue No. | Suitable for Lithotripsy Handle | Set Components | Component Catalogue No. |
|---|---|---|---|
| E120261 | Type III | 1 x Lithotripsy Handle Type III 1 x Lithotripsy Storage Case 3 x Lithotripsy Spirals 1 x Emergency Lithotripsy Spiral 1 x Lithotripsy Basket 1 x Lithotripsy Basket 1 x Lithotripsy Basket | 120600 120601 E120602 E120604 E120265N E120266N E120267N |
Instructions for Use - Lithotripsy Baskets and Lithotripsy Spirales SU (sterile)
File size:
851 KB
Type:
PDF
Leaflet Lithotripsy Baskets and Spirals - Single Use
File size:
1 MB
Type:
PDF
