Biliary Dilation Catheter

Description

Biliary dilation catheters for duodenoscopes, with continuous distal tapering over a length of 30 mm, up to the atraumatic catheter tip. For better orientation during fluoroscopy, all versions consist of a metal ring at the beginning of the distal taper and are equipped with X-ray contrasting Teflon along the entire length. The dilation catheter can be guided to the stenosis via a guide wire and gives the option of contrast medium injection at the proximal Luer-Lock connector.

  • tip diameter: varies between 3.0 Fr. and 7.0 Fr.
  • catheter diameter: between 5.0 Fr. and 12.0 Fr.
  • x-ray contrast tube
  • working length 200 cm
  • ascending tube and tip diameter for gradual dilation
  • distal metal ring (X-ray marking)
  • suitable for guide wire
  • proximal Luer lock connector for contrast medium injection

Product Images and Videos

Customer Service
Any Questions about the product? +49 281 94400-0 vertrieb (at) endo-flex.de

More Information

Biliary Dilation Catheters – Single Use

Working Length 200 cm; radiopaque teflon tube with distal metal ring; compatible with guide wire

Catalogue No. Diameter Tubus (French) Diameter Tip (French) Compatible with Guide Wire (inch) Min. Accessory Channel
E20000053 5 3 .024 2.0
E20000064 6 4 .035 2.2
E20000075 7 5 .035 2.8
E20000085 8 5 .035 3.2
E20000095 9 5 .035 3.2
E20000105 10 5 .035 3.7
E20000107 10 7 .035 3.7
E20000127 12 7 .035 4.2

Instructions for Use - Biliary Dilation Catheters SU

File size: 1,003 KB
Type: PDF

Leaflet Biliary Dilation Catheters - Single Use

File size: 151 KB
Type: PDF
