Stone Extraction Balloons

Description

Medi-Globe stone extraction balloons have a distal plastic balloon framed with X-ray markings, a double or triple-lumen plastic tube and three proximal Luer-Lock connectors as access for contrast media,  guide wire or 2-way stopcock for inflation.

Variant with 1-stage balloon catheter:

  • tube with diameters Fr. 5, 7 and 7.5mm
  • total length 200 cm
  • balloon diameters 9-12 mm and 14-16 mm

This instrument is fitted with a syringe corresponding to the maximum filling volume.



Variant with 3-stage balloon catheter:

  • tube with a diameter Fr. 7.5
  • total length 200 cm
  • balloon diameters between 9, 13 and 16 mm.

This instrument is fitted with three syringes corresponding to the respective maximum filling volume.

Product Images and Videos

Customer Service
Any Questions about the product? +49 281 94400-0 vertrieb (at) endo-flex.de

More Information

Single-Stage Stone Extraction Balloon – Double Lumen

Incl. syringe for max. air capacity; latex-free

Catalogue No. Compatible with Guide Wire (inch) Catheter Outer Diameter (French) Contrast Injection Balloon Diameter in Inflated Condition (mm) Air Capacity (ml) Working Length (cm) Min. Accessory Channel (mm)
GEB-05-17-025 .025“ 5 Above 12 1.5 200 2.8
GEB-05-23-035 .035” 7 Above 16 2.5 200 2.8



Single-Stage Stone Extraction Balloon – Triple Lumen

Incl. syringe for max. air capacity; latex-free

Catalogue No. Compatible with Guide Wire (inch) Catheter Outer Diameter (French) Contrast Injection Balloon Diameter in Inflated Condition (mm) Air Capacity (ml) Working Length (cm) Min. Accessory Channel (mm)
GEB-06-25-035 .035“ 7,5 Above 16 5.0 200 2.8
GEB-06-25-035P .035” 7,5 Below 16 5.0 200 2.8



Multi-Stage Stone Extraction Balloon - Triple Lumen

Incl. 3 syringes for max. air capacity; latex-free

Catalogue No. Compatible with Guide Wire (inch) Catheter Outer Diameter (French) Contrast Injection Balloon Diameter in Inflated Condition (mm) Air Capacity (ml) Working Length (cm) Min. Accessory Channel (mm)
GEB-07-25-035 .035“ 7.5 Above 9-13-16 1.5-2.5-5.0 200 2.8
GEB-07-25-035P .035” 7.5 Below 9-13-16 1.5-2.5-5.0 200 2.8
