Pancreatic Stent Sets

Description

  • med of PE
  • different diameters and lengths
  • versions with distal and duodenal wings, multiflap
  • curved, pigtail and S-shapes
  • laterally and continuously perforated

Product Images and Videos

Customer Service
Any Questions about the product? +49 281 94400-0 vertrieb (at) endo-flex.de

More Information

Pancreatic Stent-Set – Straight

Straight with radial holes; 1 duodenal flap; compatible with guide wire .035”

Catalogue No. Stent Size (French) Stent Length between Flaps (cm) Pusher Size (French) Pusher Length (cm)
GBS-20-05-003S 5.0 3 5.0 220
GBS-20-05-005S 5.0 5 5.0 220
GBS-20-05-007S 5.0 7 5.0 220



Pancreatic Stent-Set – S-shaped

Compatible with guide wire .035”

Catalogue No. Stent Size (French) Stent Length (cm) Pusher Size (French) Pusher Length (cm)
GBS-09-05-005S 5.0 5 5.0 220
GBS-09-05-007S 5.0 7 5.0 220
GBS-09-05-009S 5.0 9 5.0 220
GBS-09-05-012S 5.0 12 5.0 220
GBS-09-05-015S 5.0 15 5.0 220
GBS-09-07-005S 7.0 5 7.0 220
GBS-09-07-007S 7.0 7 7.0 220
GBS-09-07-009S 7.0 9 7.0 220
GBS-09-07-012S 7.0 12 7.0 220
GBS-09-07-015S 7.0 15 7.0 220



Pancreatic Stent-Set – Straight

Straight with radial holes; 1 distal and 1 duodenal flap; compatible with guide wire .035”

Catalogue No. Stent Size (French) Stent Length between Flaps (cm) Pusher Size (French) Pusher Length (cm)
GBS-10-05-003S 5.0 3 5.0 220
GBS-10-05-005S 5.0 5 5.0 220
GBS-10-05-007S 5.0 7 5.0 220
GBS-10-05-009S 5.0 9 5.0 220
GBS-10-05-011S 5.0 11 5.0 220
GBS-10-07-003S 7.0 3 7.0 220
GBS-10-07-005S 7.0 5 7.0 220
GBS-10-07-007S 7.0 7 7.0 220
GBS-10-07-008S 7.0 8 7.0 220
GBS-10-07-009S 7.0 9 7.0 220
GBS-10-07-011S 7.0 11 7.0 220
GBS-10-07-016S 7.0 16 7.0 220
GBS-10-08-005S 8.5 5 8.5 220
GBS-10-08-007S 8.5 7 8.5 220
GBS-10-08-008S 8.5 8 8.5 220
GBS-10-08-009S 8.5 9 8.5 220
GBS-10-08-011S 8.5 11 8.5 220
GBS-10-08-016S 8.5 16 8.5 220



Pancreatic Stent-Set – Straight with Single Pigtail

Single pigtail with multiple flaps; multiple drainage holes; 1 position marker; compatible with guide wire .035”

Catalogue No. Stent Size (French) Stent Length between Pigtail (cm) Pusher Size (French) Pusher Length (cm)
GBS-08-05-003S 5.0 3 5.0 220
GBS-08-05-004S 5.0 4 5.0 220
GBS-08-05-005S 5.0 5 5.0 220
GBS-08-05-006S 5.0 6 5.0 220
GBS-08-05-007S 5.0 7 5.0 220
GBS-08-05-008S 5.0 8 5.0 220
GBS-08-05-009S 5.0 9 5.0 220
GBS-08-05-010S 5.0 10 5.0 220
GBS-08-05-012S 5.0 12 5.0 220
GBS-08-07-002S 7.0 2 7.0 220
GBS-08-07-004S 7.0 4 7.0 220
GBS-08-07-006S 7.0 6 7.0 220
GBS-08-07-009S 7.0 9 7.0 220
GBS-08-07-012S 7.0 12 7.0 220
GBS-08-08-006S 8.5 6 8.5 220
GBS-08-08-009S 8.5 9 8.5 220
GBS-08-08-012S 8.5 12 8.5 220
GBS-08-10-006S 10.0 6 10.0 220
GBS-08-10-009S 10.0 9 10.0 220
GBS-08-10-012S 10.0 12 10.0 220
GBS-08-11-006S 11.5 6 11.5 220
GBS-08-11-009S 11.5 9 11.5 220
GBS-08-11-012S 11.5 12 11.5 220



Pancreatic Stent-Set – Straight with Single Pigtail

Without flap; multiple drainage holes; 1 position marker; compatible with guide wire .035”

Catalogue No. Stent Size (French) Stent Length between Pigtail (cm) Pusher Size (French) Pusher Length (cm)
GBS-18-05-003S 5.0 3 5.0 220
GBS-18-05-004S 5.0 4 5.0 220
GBS-18-05-005S 5.0 5 5.0 220
GBS-18-05-006S 5.0 6 5.0 220
GBS-18-05-007S 5.0 7 5.0 220

Pancreatic Stent – Straight, 2 Flaps

With radial holes; 1 distal and 1 duodenal flap

Catalogue No. Size (French) Length between Flaps (cm)
GBS-10-05-003 5.0 3
GBS-10-05-005 5.0 5
GBS-10-05-007 5.0 7
GBS-10-05-009 5.0 9
GBS-10-05-011 5.0 11
GBS-10-07-003 7.0 3
GBS-10-07-005 7.0 5
GBS-10-07-007 7.0 7
GBS-10-07-008 7.0 8
GBS-10-07-009 7.0 9
GBS-10-07-011 7.0 11
GBS-10-07-016 7.0 16
GBS-10-08-005 8.5 5
GBS-10-08-007 8.5 7
GBS-10-08-008 8.5 8
GBS-10-08-009 8.5 9
GBS-10-08-011 8.5 11
GBS-10-08-016 8.5 11



Pancreatic Stent – Straight, 1 Flap

With radial holes; 1 duodenal flap

Catalogue No. Size (French) Length (cm)
GBS-20-05-003 5.0 3
GBS-20-05-005 5.0 5
GBS-20-05-007 5.0 7



Pancreatic Stent – Straight with Single Pigtail

Single pigtail with multiple flaps; multiple drainage holes; 1 position marker

Catalogue No. Size (French) Length between Pigtail (cm)
GBS-08-05-003 5.0 3
GBS-08-05-004 5.0 4
GBS-08-05-005 5.0 5
GBS-08-05-006 5.0 6
GBS-08-05-007 5.0 7
GBS-08-05-008 5.0 8
GBS-08-05-009 5.0 9
GBS-08-05-010 5.0 10
GBS-08-05-012 5.0 12
GBS-08-07-002 7.0 2
GBS-08-07-004 7.0 4
GBS-08-07-006 7.0 6
GBS-08-07-009 7.0 9
GBS-08-07-012 7.0 12
GBS-08-08-006 8.5 6
GBS-08-08-009 8.5 9
GBS-08-08-012 8.5 12
GBS-08-10-006 10.0 6
GBS-08-10-009 10.0 9
GBS-08-10-012 10.0 12
GBS-08-11-006 11.5 6
GBS-08-11-009 11.5 9
GBS-08-11-012 11.5 12



Pancreatic Stent – Straight with Single Pigtail

Single pigtail without flap; multiple drainage holes; 1 position marker

Catalogue No. Size (French) Length between Pigtail (cm)
GBS-18-05-003 5.0 3
GBS-18-05-004 5.0 4
GBS-18-05-005 5.0 5
GBS-18-05-006 5.0 6
GBS-18-05-007 5.0 7



Pancreatic Stent – S-shaped

Single components

Catalogue No. Size (French) Length (cm)
GBS-09-05-005 5.0 5
GBS-09-05-007 5.0 7
GBS-09-05-009 5.0 9
GBS-09-05-012 5.0 12
GBS-09-05-015 5.0 15
GBS-09-07-005 7.0 5
GBS-09-07-007 7.0 7
GBS-09-07-009 7.0 9
GBS-09-07-012 7.0 12
GBS-09-07-015 7.0 15

Leaflet Pancreatic Stents and Stent-Sets - Single Use
