Fibrin Needles

Description

ENDO-FLEX offers fibrin needles in two versions:

  • double-lumen standard needle:The components are brought together in a "mixing chamber" before they exit the needle
  • double-lumen coaxial needle: The components connect for the first time in the tissue.

Color-coded Luer-Lock connectors are used for the targeted attachment of the fibrin components.

  • lengths: of 160, 180 and 230cm.
  • tube diameter: 2.6 mm
  • color-coded Luer-Lock connectors
  • transport protection against accidental extension of the needle before use

Product Images and Videos

Customer Service
Any Questions about the product? +49 281 94400-0 vertrieb (at) endo-flex.de

More Information

Fibrin Application Needle

Double lumen, single lumen needle; min. accessory channel 3.2mm; mixing of the adhesive components in the instrument

Catalogue No. Needle Diameter (mm) Needle Length (mm) Catheter Outer Diameter (mm) Working Length (cm)
ET272620-B 0.9 6 2.6 160
ET272620-C 0.9 6 2.6 180
ET272620-G 0.9 6 2.6 230
ET272620-C4 0.9 4 2.6 180



Fibrin Application Needle

Double lumen, coaxial needle; min. accessory channel 3.2mm; mixing of the adhesive components in the tissue

Catalogue No. Needle Diameter (mm) Needle Length (mm) Catheter Outer Diameter (mm) Working Length (cm)
ET272630-B 1.2 6 2.6 160
ET272630-C 1.2 6 2.6 180
ET272630-G 1.2 6 2.6 230

Instructions for Use - Fibrin Application Needles SU

File size: 996 KB
Type: PDF

Leaflet Fibrin Needles - Single Use

File size: 321 KB
Type: PDF
