ExPander Dilation Balloons Multi Stage

Description

Medi-Globe multi-stage dilation balloons ExPander have a clear, transparent plastic balloon that offers a uniform diameter with maximum radial force. Each balloon can gradually reach three different diameters.
Both variants, biliary and the esophageal, can be easily positioned through the endoscope using a guide wire. X-ray markings supported the exact placement.

Easy placement through the endoscope (TTS)

  • compatible with 0.035 "guide wires
  • balloon diameters from 6 mm to 15 mm (biliary) and 6 mm to 20 mm for esophageal variants

Product Images and Videos

Customer Service
Any Questions about the product? +49 281 94400-0 vertrieb (at) endo-flex.de

More Information

Esophageal Dilation Balloon – Guide Wire Compatibility

Pre-loaded hydrophilic guide wire .035“; with radiopaque markers; 3 progressive stages; total length 180 cm

Catalogue No. Balloon Diameter (mm) Balloon Length (mm) Catheter Outer Diameter (mm) Max. Pressure (psi/atm) Min. Accessory Channel (mm)
GDB-04-08-080 6–7–8 80 2.3 147/10 2.8
GDB-04-10-080 8–9–10 80 2.3 132/9 2.8
GDB-04-12-080 10–11–12 80 2.3 118/8 2.8
GDB-04-15-080 12–13.5–15 80 2.3 118/8 2.8
GDB-04-18-080 15–16.5–18 80 2.3 103/7 2.8
GDB-04-20-080 18–19–20 80 2.3 88/6 3.2



Esophageal / Colonic Balloon – Guide Wire Compatibility

Pre-loaded hydrophilic guide wire .035“; with radiopaque markers; 3 progressive stages; total length 230 cm

Catalogue No. Balloon Diameter (mm) Balloon Length (mm) Catheter Outer Diameter (mm) Max. Pressure (psi/atm) Min. Accessory Channel (mm)
GDB-04-08-055 6–7–8 55 2.3 147/10 2.8
GDB-04-10-055 8–9–10 55 2.3 132/9 2.8
GDB-04-12-055 10–11–12 55 2.3 118/8 2.8
GDB-04-15-055 12–13.5–15 55 2.3 118/8 2.8
GDB-04-18-055 15–16.5–18 55 2.3 103/7 2.8
GDB-04-20-055 18–19–20 55 2.3 88/6 3.2



Biliary Dilation Balloon – Guide Wire Compatibility

Pre-loaded hydrophilic guide wire .035“; with radiopaque markers; 3 progressive stages; total length 200 cm

Catalogue No. Balloon Diameter (mm) Balloon Length (mm) Catheter Outer Diameter (mm) Max. Pressure (psi/atm) Min. Accessory Channel (mm)
GDB-04-08-030 6–7–8 30 2.3 147/10 2.8
GDB-04-10-030 8–9–10 30 2.3 132/9 2.8
GDB-04-12-030 10–11–12 30 2.3 118/8 2.8
GDB-04-15-030 12–13.5–15 30 2.3 118/8 2.8



Inflation / Deflation System

Filling medium: liquid

Catalogue No. Description
FXB-70-20 Filling volume 70 ml, incl. manometer 0 – 20 atm, automatic plunger locking system allows comfortable operation, rotating Luer-Lock connector, transparent syringe barrel for easy detection and removal of air bubbles

Leaflet ExPander Multi-Stage Dilation Balloons - Single Use

File size: 284 KB
Type: PDF
