ESD knife

Description

ESD knives from Medi-Globe are characterized by a wide range of applications for endoscopic submucosal dissection in the esophagus and the gastrointestinal tract. The ESD knives combine two types of cutting knives (O-knife / I-knife) in one instrument and thus enable the marking and dissection of the lesions in one operation without changing instruments. The design of the ESD knife enables fast and precise dissection of the target tissue.

Medi-Globe ESD knives are available in various combinations of O and I knives. This enables the user to differentiate between different types of tissue.

Two types of knives in one instrument:

I-knife

  • Available in different lengths from 1 mm to 4 mm
  • T-shaped tip enables the target tissue to be precisely marked and prevents the knife from slipping during the cutting process

O-knife

  • with a fixed length of 4 mm and an insulated radial electrode
  • for safe dissection and prevention of perforations in the surrounding tissue

Product Images and Videos

Customer Service
Any Questions about the product? +49 281 94400-0 vertrieb (at) endo-flex.de

More Information

ESD/EMR Knife

Catalog No. Sales Unit Outer Ø Working Length Requested min. Channel Length I - Knife Length O - Knife
MEK-401D-180 Box of 10 2.4mm 180cm 2.8mm 2.0mm 4.0mm
MEK-402D-230 Box of 10 2.4mm 230cm 2.8mm 2.0mm 4.0mm
MEK-403D-180 Box of 10 2.4mm 180cm 2.8mm 3.0mm 4.0mm
MEK-404D-230 Box of 10 2.4mm 230cm 2.8mm 3.0mm 4.0mm
MEK-405D-180 Box of 10 2.4mm 180cm 2.8mm 4.0mm 4.0mm
MEK-406D-230 Box of 10 2.4mm 230cm 2.8mm 4.0mm 4.0mm
MEK-407D-180 Box of 10 2.4mm 180cm 2.8mm 1.0mm 4.0mm
MEK-408D-230 Box of 10 2.4mm 230cm 2.8mm 1.0mm 4.0mm
MEK-409D-180 Box of 10 2.4mm 180cm 2.8mm 1.5mm 4.0mm
MEK-410D-230 Box of 10 2.4mm 230cm 2.8mm 1.5mm 4.0mm
MEK-411D-160 Box of 10 2.4mm 160cm 2.8mm 2.0mm 4.0mm
MEK-412D-160 Box of 10 2.4mm 160cm 2.8mm 3.0mm 4.0mm
MEK-413D-160 Box of 10 2.4mm 160cm 2.8mm 4.0mm 4.0mm
MEK-414D-160 Box of 10 2.4mm 160cm 2.8mm 1.0mm 4.0mm
MEK-415D-160 Box of 10 2.4mm 160cm 2.8mm 1.5mm 4.0mm

Leaflet ESD/EMR Knife - Single Use

File size: 273 KB
Type: PDF
