ECO-Injectra

Description

  • distal stainless steel needle in plastic tube
  • distally conical metal head
  • different needle lengths and diameters
  • handle with locking mechanism to secure the needle

Product Images and Videos

Customer Service
Any Questions about the product? +49 281 94400-0 vertrieb (at) endo-flex.de

More Information

Bronchoscopy - ECO-Injectra

Metal tip protection; needle locking mechanism (one hand operation)

Catalogue No. Needle Diameter (mm / Gauge) Needle Length (mm) Sheath Outer Diameter (mm) Working Length (cm) Min. Accessory Channel (mm)
GSN-21-18-120 0.5/25 4 1.8 120 2.0
GSN-22-18-120 0.5/25 6 1.8 120 2.0



Gastroscopy - ECO-Injectra

Metal tip protection; needle locking mechanism (one hand operation)

Catalogue No. Needle Diameter (mm / Gauge) Needle Length (mm) Sheath Outer Diameter (mm) Working Length (cm) Min. Accessory Channel (mm)
GSN-21-23-180 0.5/25 4 2.3 180 2.8
GSN-22-23-180 0.5/25 6 2.3 180 2.8
GSN-23-23-180 0.7/22 4 2.3 180 2.8
GSN-24-23-180 0.7/22 6 2.3 180 2.8
GSN-25-23-180 1.0/19 4 2.3 180 2.8
GSN-26-23-180 1.0/19 6 2.3 180 2.8



Colonoscopy - ECO-Injectra

Metal tip protection; needle locking mechanism (one hand operation)

Catalogue No. Needle Diameter (mm / Gauge) Needle Length (mm) Sheath Outer Diameter (mm) Working Length (cm) Min. Accessory Channel (mm)
GSN-21-23-230 0.5/25 4 2.3 230 2.8
GSN-22-23-230 0.5/25 6 2.3 230 2.8
GSN-23-23-230 0.7/22 4 2.3 230 2.8
GSN-24-23-230 0.7/22 6 2.3 230 2.8
GSN-25-23-230 1.0/19 4 2.3 230 2.8
GSN-26-23-230 1.0/19 6 2.3 230 2.8

Leaflet Injection Needles - Single Use

File size: 199 KB
Type: PDF
